Small Mobile Firewood Trommel Screen With Bouncing Ball Cleaning System For Your

Product Categories
Zhengzhou Sinolion Machinery Co., Ltd.
Trust Seal
Verified Supplier
Credit Check
Supplier Assessment
Contact Now

Small Mobile Firewood Trommel Screen With Bouncing Ball Cleaning System For Your

Applicable Industries : Farms

Showroom Location : United States

Video outgoing-inspection : Provided

Machinery Test Report : Provided

Marketing Type : New Product 2023

Warranty of core components : 1 Year

Core Components : PLC, Engine, Bearing, Gearbox, Motor, Pump

Condition : New

Type : Circular

Application : Food Processing, medicine, chemicals, Metallurgy

Place of Origin : Henan, China

Brand Name : sinolion

Voltage : 220V / 380V / As client's demand

Dimension(L*W*H) : 500*500*550mm

Weight : 3000 KG

Warranty : 1.5 years

Product name : Rotary Sceen

Keyword : Rotary Vibrating Separator

Motor : Two Vibration Motor

Material : Carbon Steel

After-sales Service Provided : Online Support

Usage : Separation Screening

Function : Screening\separation\sorting\sieving

Cleaning system : Bouncing Ball

Noise : Lower

Packaging Details : All products will be processed to be rustproof and moisture proof before delivery.
20GP container or 40GP container
Equipment is packed with plastic wrap or steel case, depends on machine weight.
Motor is packed with steel case or wooden case.

Port : Qingdao, Tianjin, Lianyungang, Shanghai Guangzhou( as client request)

Supply Ability : 50 Set/Sets per Month gold trommel screening plant

Price : $13,100.00/sets

MOQ : 1 unit

Contact Now

Small Mobile Firewood Trommel Screen With Bouncing Ball Cleaning System For Your
Small Mobile Firewood Trommel Screen With Bouncing Ball Cleaning System For Your
Small Mobile Firewood Trommel Screen With Bouncing Ball Cleaning System For Your
High Performance Factory Price Wood Chip Drum Screen Firewood Trommel Screen
The firewood trommel screen will efficiently remove all fines (dirt, gravel, wood chips & splinters) through the fine screen and most of the kindling and smaller pieces of wood through the coarse screen. The firewood trommel screen is designed as an add on to a bulk processing system. Cleaning the wood in the last step before packaging for bulk retail sale. For wood yards this means the wood is cleaner, more saleable and results in more accurate weight measurement. With a constantly loaded feeding hopper, the capacity of this machine is estimated in excess of 60m3 per hour. Talk with our team about customising a firewood trommel screen to suit your requirements.
Small Mobile Firewood Trommel Screen With Bouncing Ball Cleaning System For Your
Small Mobile Firewood Trommel Screen With Bouncing Ball Cleaning System For Your
Small Mobile Firewood Trommel Screen With Bouncing Ball Cleaning System For Your
Small Mobile Firewood Trommel Screen With Bouncing Ball Cleaning System For Your
Small Mobile Firewood Trommel Screen With Bouncing Ball Cleaning System For Your
Small Mobile Firewood Trommel Screen With Bouncing Ball Cleaning System For Your
Small Mobile Firewood Trommel Screen With Bouncing Ball Cleaning System For Your

Structure and Principle

Firewood tumbler is composed of feeding hopper, screen drum, chassis, wheel, transmission device, and control cabinet(optional parts: diesel engine generator and belt conveyor). It is a new type of mobile screening platform, and suitable for the power plant, coking plant, building materials, metallurgy, chemical, mining and other industries. It has the features that less investment, less labor, simple operation and flexible.
After the materials is feed into the drum, on the one hand, materials being screened along with the rotation of drum, on the other hand, the bigger materials flow forward along the direction of slope and be separated by the screen with different number of meshes. The different materials fall into different hopper and then be sent to different finished product stacks by manpower or belt conveyor.
Small Mobile Firewood Trommel Screen With Bouncing Ball Cleaning System For Your
Product Name
Mobile Firewood Trommel Screen
Model
Capacity
(t/h)
Power
(kw)
Diameter
(mm)
Length
(mm)
FTS1230
60
3
1200
3000
Small Mobile Firewood Trommel Screen With Bouncing Ball Cleaning System For Your
Small Mobile Firewood Trommel Screen With Bouncing Ball Cleaning System For Your
Small Mobile Firewood Trommel Screen With Bouncing Ball Cleaning System For Your
Small Mobile Firewood Trommel Screen With Bouncing Ball Cleaning System For Your
Small Mobile Firewood Trommel Screen With Bouncing Ball Cleaning System For Your
Small Mobile Firewood Trommel Screen With Bouncing Ball Cleaning System For Your
Small Mobile Firewood Trommel Screen With Bouncing Ball Cleaning System For Your
Small Mobile Firewood Trommel Screen With Bouncing Ball Cleaning System For Your
Small Mobile Firewood Trommel Screen With Bouncing Ball Cleaning System For Your
Small Mobile Firewood Trommel Screen With Bouncing Ball Cleaning System For Your
Small Mobile Firewood Trommel Screen With Bouncing Ball Cleaning System For Your
Small Mobile Firewood Trommel Screen With Bouncing Ball Cleaning System For Your
Small Mobile Firewood Trommel Screen With Bouncing Ball Cleaning System For Your
Small Mobile Firewood Trommel Screen With Bouncing Ball Cleaning System For Your

Wholesale Small Mobile Firewood Trommel Screen With Bouncing Ball Cleaning System For Your from china suppliers

Small Mobile Firewood Trommel Screen With Bouncing Ball Cleaning System For Your Images
